What is a digital pressure gauge?

A digital pressure gauge is an electronic instrument that operates with electronic parts and displays the pressure value on an integrated digital display.

How do digital pressure gauges work?

Digital pressure gauges work by converting the applied pressure into an electronic signal that is then displayed numerically on a digital display. Digital pressure gauges use a sensor/transducer to convert the pressure value into an electronic signal that is then translated into a digital reading.

How often do digital pressure gauges need to be calibrated?

It is recommended at least once every twelve months. Calibration may be required more frequently, subject to the gauge operation time, pressure medium, environmental factors, as well as standard operating conditions and general maintenance.

What is the difference between digital pressure gauges and analogue pressure gauges?

Digital pressure gauges convert the pressure value into a signal through the use of a sensor/transducer and displays the correlated reading on a digital display. Analogue pressure gauges use a mechanical component, such as a bourdon tube, to sense pressure. The bourdon tube is linked to a circular scale dial and needle that rotates mechanically with the pressure.

Are digital pressure gauges more accurate than analogue pressure gauges?

Digital pressure gauges are more accurate than analogue pressure gauges due to being engineered with modern technology. Digital pressure gauges are electronic and only rely on the pressure being converted to an electronic signal in order to be measured. Due to their limited reliance on mechanical parts, digital pressure gauges are less at risk of wear and tear, better maintaining their accuracy over time.

PDK PDR100 Digital Pressure Gauge

Technical Datasheet

The PDK PDR100 Digital Pressure Gauge is a low-cost, entry-level gauge that is perfect for most applications. With a 68mm dial that features a backlit LCD display, the PDR100 also has the capability to display a range of pressure units from bar, Mbar to psi, kPa and more. With a full-scale accuracy rating of 0.5%, the PDR100 is feature-packed, reliable and accurate.

Please note: For kPa measurements, this model will only display up to 2000.

Features:

68mm Bottom-Entry Digital Pressure Gauge
G1/4" BSPP thread connection
Perfect low-cost, entry-level digital pressure gauge
Pressure ranges available up to 100 bar
0.5% full-scale accuracy
Easy-to-change pressure unit function.
Full selection of pressure units available to display: mbar, bar, MPa, mmH²0, inHg, mmHg, kgf/cm², atm, psi, kPa
Auto-off Function
Backlit LCD display
Calibration function

PDK PDR100 Digital Pressure Gauge

Features:
